Architectural BIM Services

At BuildSmart TechBIM, we transform sketches and 2D intent into a coordinated, data-rich 3D Building Information Model that guides decisions from concept to handover. Our Architectural BIM Services are designed for architects, contractors, developers, and owner teams who want fewer surprises, faster approvals, and predictable outcomes. By establishing shared coordinates, level/zone strategies, and strict naming conventions on day one, we give every stakeholder a single source of truth through design, procurement, construction, and FM.

We begin with a practical BIM Execution Plan (BEP) that sets responsibilities, LOD targets, and information exchanges. Each model element is created with the right level of development for the current stage—never over-modeled, never under-specified.

Our architectural scope covers concept massing, space planning, unit typologies, facade systems, stairs/railings, wet areas, RCPs, finishes, and door/window schedules—complemented by reusable parametric families.

What You Get with Architectural BIM

3D Architectural Modelling

Walls, floors, ceilings, openings, finishes, rooms & zones with shared coordinates for reliable collaboration.

Design Development Support

Options, area programs, facade studies, room data sheets, and quick iterations for stakeholder buy-in.

Construction Documentation

Plans, sections, elevations, details, legends, schedules, and BOQ-ready exports aligned to standards.

Clash-Free Coordination

Early resolution with Structure/MEP, builder’s work openings, access tolerances, and issue logs with priorities.

Parametric Family Creation

Doors, windows, casework, furniture, equipment—parameter-driven, reusable, and project-standardized.

4D/5D-Ready Data

Model structured for time sequencing and cost control to cut variation orders and procurement surprises.

Deliverables & Outcomes

Deliverables: Coordinated RVT/IFC model with levels, grids, zones, and shared coordinates; GA plans, elevations, sections, and RCPs; detail sheets and legends; door/window and room schedules; quantity-ready exports; clash logs with screenshots, priorities, and due dates; curated parametric family libraries; and tidy sheet registers aligned to your title blocks and print standards.

Outcomes: Fewer RFIs, faster approvals, predictable procurement, and smoother handovers. Site teams see issues before they become rework. Stakeholders get transparent options with measurable impact on cost, time, and facility performance.

Industries & Use-Cases

We support residential towers, villas, commercial fit-outs, retail & F&B, hospitality, healthcare, education, industrial parks, logistics warehousing, and data centers. From feasibility massing to as-built capture, our Architectural BIM unlocks clear decisions at every stage—especially where local compliance, tight sites, and phased delivery are critical.

How We Work

  • Discovery & BEP: We capture objectives, information milestones, classification, and exchange formats, then publish a BIM Execution Plan the team follows.
  • Model Setup: Levels, grids, zones, and shared coordinates are established once—preventing compounding errors across disciplines.
  • Authoring & QA: Disciplined templates, view standards, family libraries; automated scripts check naming, worksets, warnings, and file health.
  • Coordination: Structured clash tests with Structure/MEP, builder’s work, and access tolerances. Issues tracked via BCF with owners and due dates.
  • Documentation: Clean, consistent sheets—plans, sections, elevations, details, and schedules—ready for tender and construction with revision control.
  • 4D/5D/IFC: Packaged model data for planning and cost control; openBIM exchanges keep your ecosystem flexible.

Why BuildSmart TechBIM

  • Standards that stick: ISO 19650-inspired processes, region-ready templates, and client-specific BEPs keep delivery predictable.
  • Constructability first: Architectural fidelity with practical detailing so site teams can build safely and efficiently.
  • Automation where it matters: Dynamo checks and naming bots reduce manual errors and speed up iterations.
  • Transparent communication: Visual markups, clash snapshots, and executive summaries help non-technical stakeholders approve faster.
  • Lifecycle mindset: Data structured for facilities and asset management—not just drawings.
